Vertical Tapered Mixer/Homogenizer Mixer
Product Description
Main Application
The equipment is driven by an explosion-proof motor, driven by a helical gear reducer, and driven by a ribbon agitator. The
animal material rotates along the wall of the cone and rises from bottom to top. After the material reaches the highest point, it is automatically moved to the vortex by gravity and inertia. The center returns to the bottom of the cone cylinder. A series of processes force the material to be heated in the cone cylinder, interdiffusion, convection, shearing, misalignment and blending, so that the material can be repetitively reciprocated in all directions to complete the material. The belt and the wall surface of the cylinder are exchanged at a high frequency for heat exchange, and the effect of heating and drying is achieved in a short time.
| Model | CW-180 | CW-300 | CW-500 | CW-1000 | CW-2000 | CW-3000 | CW-4000 |
| Power(Kw) | 1.1 | 1.1 | 2.2 | 4 | 7.5 | 11 | 11 |
| Capacity(kg/batch) | 40 | 60 | 100 | 200 | 400 | 600 | 800 |
| Total volume | 0.18 | 0.3 | 0.5 | 1 | 2 | 3 | 4 |
| Mixing time(min) | 4-8 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 |
| Speed(r/min) | 12 | 12 | 12 | 10 | 10 | 8 | 8 |
1. Multifunctional “Three in One” (filtering, washing and drying)
3. Sterile double-cone dryer
4. Rake Vacuum Dryer /Paddle Vacuum Dryer
5. Plate-fin Heat Exchanger
➤Our advantage
1. Special Equipment: Pressure Equipment, Equipment made of anti-corrosion materials,
Equipment made of anti-corrosion materials includes: anti-corrosion lining plastic/ PTFE/ enamel,
Ti/HC22/Mone11
2.Customized Design: Double-Cone in 20L-20m³
Rake Dryer (with mechanical seal) in 16 m³
DN300-DN600 “Three in One”
3.Design/Calculation Software
➤Scope of business
1. On-site Inspection
2.Technical Innovation Plan for Equipment Technical Improvement Plan for Equipment’s Structure Optimization Fast and Effective Solution to Equipment Malfunctions Highly Efficient and Precise On-site Construction Service Commitment to a Deadline in Customization A Full Range of long-term on-site technical maintenance service
3. Maintenance
4. Technical Solutions
5.On-site Testing and Training
6. Spare Parts
