Industrial Hastelloy Vacuum Agitated Nutsche Filter
Basic Info
Model No.: OEM
Product Description
Products Description
The filtering,washing,drying(three in one)machine is a solid-liquid equipment with the functions of filtration,washing,drying reaction and residue discharging automatically. This filter can be divided into two in one structure ( filtering and washing) and three in one structure (filtering, washing and drying).It has good adaptability, particularly suitable for slurry is difficult to filtration and flammable, toxic, volatile, pollution and other materials, filtration, washing and drying operations in one.The utility model has the advantages of simple structure, simple process flow, high production efficiency, no cross pollution, convenient material replacement and high automation degree. At the same time, it can greatly reduce the volume of the clean workshop.
Applications and Features
Material: SS304, SS316L, Ti, Hastelloy-C, PTFE lined or other materials
Applications:It is widely applied in the industries, such as pharmaceutical, chemical engineering, agrochemical, food, etc. It can realize the continuous operation in vacuum, and even more suitable for producing sterile and poisonous products.
➤Washing stage: Further purification of filter cake, rinse and dehydration of mother liquid remained. Mix the lotion and the filter cake via up and down of agitator to make the filter cake slurry finally, then the filter cake can get the full wash.
➤Drying stage: Dehydrating and drying the filter cake. Agitator will scrape filter cake loose by layers while the sidewall; the bottom of filter plate and agitator will heat the filter cake at the same time. Moreover, the vacuum inside the equipment will accelerate the evaporating speed; the entered hot nitrogen will take away the damp and accelerate the speed of desiccation.
All the steps, including filtering, washing and drying, can be completed in one set of equipment. Drying treatment can be realized due to the heating jacket on the equipment.
➤Continuous operation
As filtering and drying is operated in one set of equipment, so there is no need to deal with wet filter cake. The final dry products can be transferred to weighing, packaging and other sections by machines.
Non-technical staffs only need to take simple training of operation. Technicians do not have to monitor the process all the time,including opening, closing, automatic feeding and discharging.
➤Proper cleaning
Agitated Nutsche Filter Dryer (filtering, washing and drying) sprays and stirs automatically, so filter cake can be properly cleaned while the amount of sewage and the cost of wastewater treatment can be reduced.
➤Clean Production
The dust catcher on the multifunctional filtering and drying equipment can collect dust after drying process, which meets the requirement of clean production.
Specification | Capacity(m³) | Filtering area(㎡) | Electrical motor power(kw) |
φ800 | 0.6m³ | 0.5㎡ | 4kw |
φ1000 | 1.2m³ | 0.8㎡ | 5.5kw |
φ1200 | 1.5m³ | 1㎡ | 5.5kw |
φ2000 | 4m³ | 3㎡ | 11kw |
φ3000 | 10.2m³ | 7㎡ | 22kw |
φ4000 | 22m³ | 13㎡ | 45kw |
... | | | |
φ4600 | 30m³ | 16㎡ | 75kw |
Zhanghua VS Other | New advanced airtight technology, vacuum ≤ 50PA,Improve the quality of user products, can be used in the production of aseptic grade products |
Quick open chassis,The maximum size is 3000mm diameter fast opening chassis,Save time and manpower, safe operation, simple and easy | |
Design of combined outlet,More reliable sealing performance, high safety, even power failure will not leak | |
High precision synchronization of stirring, chassis lifting, chassis locking,Improve the transmission precision of the equipment, increase the service life and safety reliability | |
PLC and DCS automatic control,Save time and manpower, safe operation, simple and easy | |
On - line monitoring of main shaft bellows,Detect the leakage at the first time, and take corresponding measures to reduce the loss of materials | |
On line cleaning of vacuum filter, complete on line cleaning of highest parts of equipment with minimum cleaning fluid | |
European technology, China's earliest three-in-one manufacturer,Reliable performance, 20 years of experience, has been produced no less than 300 |
